HD Programmable Power Module

Product Details

Replace your bench power supplies, scope, and current probes with the HD Programmable Power Module: A powerful and cost-effective alternative.

The PPM range is intended mainly for testing of SSDs, HDDs and other PCIe, SAS and SATA devices. Fixtures are available to allow all common devices to be instrumented in seconds.

Simple screw terminal fixtures are also available so you can test any device that fits within the power spec of the PPM.

The HD PPM has fast sampling for highly accurate power measurements, and can record for hours or even days using Quarch Power Studio or our simple automation scripts.

The output voltages are fully controllable, allowing creation of complex ramp, glitch and brownout patters across both rails. Our patented multi-shunt mechanism allows seamless capture from 100uA to the peak supply of 9.2Amps

Trusted by major SSD manufacturers across the industry for over 10 years. Get the data you need to improve your products today!

SSD power consumption tests using Quarch PPM

Behind The Scenes: SSD Testing In 2019 With Quarch’s HD Power Module

Features

This HD Power Module is a flexible power margining and measurement tool and a significant upgrade on the XLC module. This version has 12V and 5V (switchable to 3V3) outputs and is ideal for SAS, SATA and PCIe based devices. The outputs can be set automatically when used with advanced Quarch fixtures.

Each rail can be programmed from 0 to 120% of its nominal voltage. The voltage and current of each output can be simultaneously recorded to provide accurate power consumption measurement.

The module allows programming of arbitrary voltage output waveforms which can be used to simulate power-up ramps, power failures, noisy power sources and much more. Patterns can be created over a range of microseconds to minutes, allowing a wide range of testing options.

A high-speed record feature provides an oscilloscope-like function to record the output voltage, current and power consumption of the attached device.

A range of injection fixtures allow the module to inject power into a variety of devices.

Dual output
Programmable output waveforms
Flexible power margining
High-speed measurement and recording
Easy measurement of voltage, current and power
Simultaneous sampling of voltage and current on both outputs
Accurate power consumption measurement
External triggering option available
Simple test automation from any standard scripting language
Supports advanced power injection fixtures.

Technical

0–6V and 0–14.4V outputs
5A continuous output current at nominal voltage
9.2A for up to 10 Seconds
1uS pattern step resolution
1V/us output slew rate (no load)
250kSps measurement sampling rate
Indefinite streamed measurements at 16uS and higher
± (2 mA + 1%) @ 1–3000mA accuracy
± (2 uA + 2%) @ 100uA–1mA accuracy
USB and LAN control options (LAN only on QTL1995)
64Mbit memory depth
2x SMA triggering connectors.

Triggering

2x triggering connectors
3.3 volt trigger
Start/stop pattern on external trigger
Start/stop measurement on external trigger
Trigger out on power/current threshold
Trigger out on pattern start
Trigger out on measurement start.

Versions

QTL1999 – HD Programmable Power Module

The standard version of the module.
USB and LAN control.

QTL1995 – HD Programmable Power Module x6

Rack-mounted 1U with 6 outputs. This version includes SMA trigger IN/OUT connections, to link to external test equipment, such as an analyzer. This allows you to begin power disruptions or measurement at a precise time within the data stream. Similarly, you can trigger the analyzer to record based on a signal from the Power Module, such as the power consumption passing a set threshold.
LAN control only.

Servicing

Repair and calibration services are available from the Quarch offices in the UK. Contact your reseller for a quote.

A calibration service is also available in the US via Simco: https://www.simco.com/

It is possible to calibrate on your own lab and this may be useful for sites with many units. This requires a Keithley 2460 and a QTL2294 (Calibration switchbox kit)
